Choice of 12" or 16" Damp Listed Ceiling Mount
The MDRC-LED is a craftsman-inspired square ceiling fixture that combines a steel housing and aluminum chassis with a 0.080" thick white textured acrylic diffuser. Optional 0.080" thick alabaster acrylic lenses — Amber Honey, Beige, and Opal — are available to enhance warmth and light quality. The cage-style frame gives the fixture a distinctive lantern character suited to craftsman, traditional, and transitional interior and exterior programs. Custom cage styles are available from the factory.
Two sizes are offered — 12" (5" H × 11.5" W) and 16" (7" H × 15.5" W) — both mounting via center lockup hardware to standard J-boxes. Dimming is standard to 10% via 0–10V, with TRIAC/ELV available on qualifying configurations. Optional battery backup (0–10V only, depth increases 1.5") and a concealed occupancy sensor (OCCHFA) are available for enhanced control.
The MDRC-LED is UL and CUL Listed for damp locations, Energy Star listed on select configurations, Title 24/JA8 compliant on F1O, F1P, and F1Q configurations, and BABA compliant. A 5-year LED component warranty is standard.
The MDRC-LED is a craftsman-inspired square ceiling fixture that combines a steel housing and aluminum chassis with a 0.080" thick white textured acrylic diffuser. Optional 0.080" thick alabaster acrylic lenses — Amber Honey, Beige, and Opal — are available to enhance warmth and light quality. The cage-style frame gives the fixture a distinctive lantern character suited to craftsman, traditional, and transitional interior and exterior programs. Custom cage styles are available from the factory.
Two sizes are offered — 12" (5" H × 11.5" W) and 16" (7" H × 15.5" W) — both mounting via center lockup hardware to standard J-boxes. Dimming is standard to 10% via 0–10V, with TRIAC/ELV available on qualifying configurations. Optional battery backup (0–10V only, depth increases 1.5") and a concealed occupancy sensor (OCCHFA) are available for enhanced control.
The MDRC-LED is UL and CUL Listed for damp locations, Energy Star listed on select configurations, Title 24/JA8 compliant on F1O, F1P, and F1Q configurations, and BABA compliant. A 5-year LED component warranty is standard.
Material: Steel housing and aluminum chassis
Lens Material: 0.080" white textured acrylic (WTP) and white smooth polycarbonate (WSP) standard; optional alabaster lenses: Amber Honey (AHA), Beige (BAA), Opal (OAA) — 0.080" thick
Mounting: Ceiling mount — center lockup with hardware included; custom cage styles available
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MDRC-12: 5" H × 11.5" W
Dimensions: MDRC-16: 7" H × 15.5" W
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
Title 24 / JA8: Yes — F1O, F1P & F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and aluminum chassis
Lens Material: 0.080" white textured acrylic (WTP) and white smooth polycarbonate (WSP) standard; optional alabaster lenses: Amber Honey (AHA), Beige (BAA), Opal (OAA) — 0.080" thick
Mounting: Ceiling mount — center lockup with hardware included; custom cage styles available
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: MDRC-12: 5" H × 11.5" W
Dimensions: MDRC-16: 7" H × 15.5" W
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
Title 24 / JA8: Yes — F1O, F1P & F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The MDRC-LED brings craftsman-inspired ceiling lighting to a broad range of interior and covered exterior environments. Its cage-style frame, alabaster lens options, occupancy sensor capability, and BABA compliance make it well-suited to hospitality, residential, and institutional applications where character and performance both matter.
Ideally Suited For:
• Hotel guestroom and suite ceiling lighting
• Craftsman-style residential and multifamily residential interiors
• Covered porch and breezeway ceiling lighting (damp rated)
• Senior living facility common areas and dining rooms
• Hospitality and boutique property public spaces with traditional or craftsman aesthetics
Key Features & Options:
• Two sizes: MDRC-12 (5" H × 11.5" W) and MDRC-16 (7" H × 15.5" W)
• Craftsman-style cage frame
• White textured acrylic and white smooth polycarbonate diffuser options
• Optional alabaster lens materials: Amber Honey (AHA), Beige Alabaster (BAA), Opal Alabaster (OAA)
• Custom cage styles available — consult factory
• 0–10V dimming; TRIAC/ELV on qualifying configurations
• Optional battery backup (BB10 — depth increases 1.5"; 0–10V only)
• Optional concealed occupancy sensor (OCCHFA)
• Energy Star listed — select configurations
• Title 24 / JA8 compliant — F1O, F1P & F1Q configurations
• BABA compliant — made in America
• 5-year LED component warranty (optional 10-year available)
• UL and CUL Listed — DAMP location
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 2057
- 2115
- 2420
- 4000
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 81
- 91
Shape
- Spherical
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 9
- 10
- 13
- 15
- 18
- 23
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
