BRLWBRLW
11" Damp Listed Wall Sconce
The BRLW-LED is a refined lantern-style wall luminaire constructed from a steel housing and chassis. Its open top and bottom design delivers up/down light distribution, while a center lockup with hardware included ensures secure, rattle-free installation. Custom cage styles are available to complement a broad range of architectural aesthetics.
The standard diffuser is .060" thick white textured polycarbonate; optional alabaster lenses in amber honey, beige, and opal (.080" thick acrylic) are available to warm and soften the light character. Multiple module configurations support both 0–10V and TRIAC/ELV dimming, covering diverse dimmer compatibility requirements. Optional accessories include a concealed occupancy sensor (O2A configuration only) and battery backup for emergency egress (0–10V configurations only).
The BRLW-LED is ADA compliant, Energy Star listed on qualifying configurations, and Title 24/JA8 compliant on F1O and F1P configurations. It is UL and CUL listed for DAMP locations and backed by a 5-year warranty on LED components, with an optional 10-year warranty. Proudly made in America.
Resources
Material: Steel housing and chassis
Lens Material: .060" white textured polycarbonate standard; optional .080" acrylic alabaster lenses: Amber Honey (AHA), Beige Alabaster (BAA), Opal Alabaster (OAA)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: BRLW-11: 11" H × 7¼" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 3000K – 3500K – 4000K
Energy Star: Yes — F1H, F1O, F1P, and F1J configurations
Title 24 / JA8: Title 24 / JA8 Compliant — F1O and F1P configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The BRLW-LED is a classic lantern-profile LED wall sconce that pairs timeless styling with modern LED efficiency and compliance credentials. Energy Star listed across multiple configurations and ADA compliant, it is a strong specification for projects where aesthetic appeal and regulatory compliance must coexist.
Ideally Suited For:
• Hotel and resort entrances, lobbies, and porte-cochères
• Residential and multi-family building exteriors and covered areas
• Historic renovation and adaptive reuse projects
• Retail and mixed-use corridor and storefront lighting
• Educational and institutional campus walkways and courtyards
Key Features & Options:
• ADA compliant — 4" projection from wall
• Energy Star listed — F1H, F1O, F1P, and F1J configurations
• Title 24/JA8 compliant — F1O and F1P configurations
• Up/down light distribution through open top and bottom
• White textured polycarbonate diffuser standard (.060" thick)
• Optional alabaster lenses: Amber Honey, Beige Alabaster, Opal Alabaster (.080" acrylic)
• Custom cage styles available
• 0–10V dimming standard; TRIAC/ELV on qualifying configurations
• Optional concealed occupancy sensor — OCCHFB (O2A configuration only)
• Optional battery backup — BB10 (10W, 1170lm, 90 min); 0–10V only
• UL/CUL listed — DAMP location
• Field-replaceable LED module
• 5-year warranty on LED components; optional 10-year warranty available
• Proudly made in America — BABA compliant options available
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 1600
- 2820
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 10
- 12
- 15
- 20
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
