PLBVPLBV
24" 36" or 48 Damp Listed Linear & Vanity Lighting
The PLBV-LED is a clean-lined LED linear vanity fixture featuring a steel chassis with a clear white smooth acrylic diffuser and matching acrylic end caps. Available in multiple lengths, the PLBV-LED delivers bright, even illumination ideal for bath, vanity, and corridor applications. Solid white end cap options are also available for a finished look.
Dimming to 10% is standard, with 0–10V and TRIAC/ELV options available depending on configuration. Optional battery backup is available for emergency egress on qualifying 0–10V configurations. The fixture mounts to a standard J-box via slotted anchor holes.
The PLBV-LED is ADA compliant, Build America Buy America Act compliant, and UL and CUL Listed for DAMP locations. It carries a 5-year warranty on LED components, with a 10-year option available. Proudly made in America.
The PLBV-LED is a clean-lined LED linear vanity fixture featuring a steel chassis with a clear white smooth acrylic diffuser and matching acrylic end caps. Available in multiple lengths, the PLBV-LED delivers bright, even illumination ideal for bath, vanity, and corridor applications. Solid white end cap options are also available for a finished look.
Dimming to 10% is standard, with 0–10V and TRIAC/ELV options available depending on configuration. Optional battery backup is available for emergency egress on qualifying 0–10V configurations. The fixture mounts to a standard J-box via slotted anchor holes.
The PLBV-LED is ADA compliant, Build America Buy America Act compliant, and UL and CUL Listed for DAMP locations. It carries a 5-year warranty on LED components, with a 10-year option available. Proudly made in America.
Material: Steel chassis
Lens Material: White smooth acrylic diffuser with acrylic end caps; optional solid white end caps
Mounting: Standard J-box via slotted anchor holes
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
PLBV-24: H 4 3/4" × D 4" × L 25 1/2"
PLBV-36: H 4 3/4" × D 4" × L 37 1/2"
PLBV-48: H 4 3/4" × D 4" × L 49 1/2"
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K
Energy Star: Yes — qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel chassis
Lens Material: White smooth acrylic diffuser with acrylic end caps; optional solid white end caps
Mounting: Standard J-box via slotted anchor holes
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
PLBV-24: H 4 3/4" × D 4" × L 25 1/2"
PLBV-36: H 4 3/4" × D 4" × L 37 1/2"
PLBV-48: H 4 3/4" × D 4" × L 49 1/2"
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K
Energy Star: Yes — qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The PLBV-LED from Lightway is a versatile LED linear vanity bar built for commercial and institutional environments. Available in multiple lengths with energy-efficient LED performance, BABA compliance, and ADA-compliant profile, it is an excellent choice wherever durable, specification-grade bath and vanity lighting is required.
Ideally Suited For:
• Commercial and institutional restrooms and vanity areas
• Healthcare and hospitality bathrooms
• Multi-family residential bath and corridor lighting
• Educational and government facility lavatories
• Transit facility and public restroom applications
Key Features & Options:
• ADA compliant — 4" depth
• BABA compliant — proudly made in America
• Multiple lengths available
• Dimming to 10% standard — 0–10V and TRIAC/ELV options
• Optional battery backup (0–10V configs, 90-minute)
• Solid white end cap option for a finished aesthetic
• Energy Star listed configurations
• Field replaceable LED module
• 5-year LED warranty; 10-year option available
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 2420
- 3630
- 4840
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 18
- 27
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
