BDYWBDYW
9" Tall Wet Listed Wall Lighting
The BDYW-LED is a compact half-globe wall pack featuring cast aluminum housing with an aluminum reflector and clear tempered glass lens. The Dark Sky-compliant cutoff design directs light downward for effective perimeter and security illumination without upward glare. Wall mounting bracket attaches to a 4" recessed outlet box. Optional photocell (option 21, 120V or 277V) and battery backup (BB10, 0–10V only) are available.
LED performance delivers CRI greater than 90, 3-step MacAdam color binning, and lumen maintenance exceeding 60,000 hours. The replaceable LED module is standard. 0–10V dimming is standard. The single configuration operates at 18W delivering 2,420 source lumens. Operates on universal 120–277V.
The BDYW-LED is Dark Sky compliant and UL and CUL listed for WET locations. Proudly made in America. Backed by a 5-year warranty on LED components with an optional 10-year warranty.
Resources
Material: Cast aluminum housing with aluminum reflector
Lens Material: Clear tempered glass (CEG)
Mounting: Wall mounting bracket — attaches to 4" recessed outlet box
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Dimensions: BDYW-7: 9 1/8" H × 18 1/8" W × 9 1/8" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The BDYW-LED is a WET-rated, Dark Sky-compliant half-globe wall pack that provides efficient downward security and perimeter illumination. Its cast aluminum construction and optional photocell make it a dependable choice for outdoor commercial and residential applications.
Ideally Suited For:
• Building exterior perimeter and security lighting
• Parking structure and lot entrances
• Commercial and industrial exterior walls
• Dark Sky-sensitive residential and civic areas
• Campus and institutional exterior lighting
Key Features & Options:
• UL/CUL listed WET location — fully outdoor rated
• Dark Sky compliant — cutoff design prevents upward glare
• Cast aluminum housing with aluminum reflector
• Clear tempered glass lens
• Optional photocell — 120V or 277V (option 21)
• Battery backup — BB10 (10W / 1,170lm / 90 min, 0–10V only)
• 90 CRI available — consult factory
• 0–10V dimming standard
• 5-year warranty with optional 10-year upgrade
Ratings & Compliance
- ARRA
- Buy America
- Buy American Act (BAA)
- DarkSky Approved
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 2420
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 18
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
