13" 15" 18" Tall Wet Listed Wall Lighting
The VALW-LED is a mission-style wall lantern offered in three sizes, built around a steel housing and chassis with a white textured polycarbonate diffuser; an optional white smooth polycarbonate or amber honey, beige, or opal alabaster acrylic lens can be specified for a different light character.
A closed top eliminates upward light pollution, and center lockup hardware simplifies installation. The fixture dims to 10% standard, with configurations available that are Energy Star qualified and Title 24/JA8 compliant, and an optional photocell and battery backup (on the two larger sizes) extend its functionality.
The VALW-LED is ADA compliant and wet-location UL/CUL listed, and is backed by Lightway's standard LED component warranty; consult the factory for custom cage styles.
The VALW-LED is a mission-style wall lantern offered in three sizes, built around a steel housing and chassis with a white textured polycarbonate diffuser; an optional white smooth polycarbonate or amber honey, beige, or opal alabaster acrylic lens can be specified for a different light character.
A closed top eliminates upward light pollution, and center lockup hardware simplifies installation. The fixture dims to 10% standard, with configurations available that are Energy Star qualified and Title 24/JA8 compliant, and an optional photocell and battery backup (on the two larger sizes) extend its functionality.
The VALW-LED is ADA compliant and wet-location UL/CUL listed, and is backed by Lightway's standard LED component warranty; consult the factory for custom cage styles.
Material: Steel housing and chassis
Lens Material: White textured polycarbonate standard; optional white smooth polycarbonate or amber honey, beige, or opal alabaster acrylic lens
Mounting: Center lockup, hardware included
ADA Compliant: Yes — 4–6" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: VALW-13: 13" H x 7¼" W x 4" D
VALW-15: 14¾" H x 8¼" W x 4" D
VALW-18: 19⅝" H x 11" W x 6" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available in Energy Star-qualified configurations (F1O, F1P, F1H, F1J)
Title 24 / JA8: Title 24/JA8 compliant (F1O and F1P configurations only)
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and chassis
Lens Material: White textured polycarbonate standard; optional white smooth polycarbonate or amber honey, beige, or opal alabaster acrylic lens
Mounting: Center lockup, hardware included
ADA Compliant: Yes — 4–6" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: VALW-13: 13" H x 7¼" W x 4" D
VALW-15: 14¾" H x 8¼" W x 4" D
VALW-18: 19⅝" H x 11" W x 6" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available in Energy Star-qualified configurations (F1O, F1P, F1H, F1J)
Title 24 / JA8: Title 24/JA8 compliant (F1O and F1P configurations only)
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The VALW-LED scales a closed-top mission lantern design across three sizes, with ADA, Energy Star, and Title 24/JA8-compliant configurations available for California energy-code projects.
Ideally Suited For
• Building entries and porches
• Garden and courtyard walls
• California Title 24/JA8 energy-code projects
• Traditional and craftsman-style architecture
Key Features & Options
• Three sizes (13", 15", 18") for scalable presence
• ADA compliant
• Closed top eliminates upward light pollution
• Title 24/JA8-compliant configurations available (F1O, F1P)
• Energy Star-qualified configurations available
• Custom cage styles available
• Optional alabaster lens accents (amber honey, beige, opal)
• Optional photocell
• Optional battery backup (15" and 18" sizes)
• Wet-location UL/CUL listing
• Proudly made in America; BABA-compliant options always available
• 5-year warranty on LED components, with optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- JA8
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 863
- 1361
- 1400
- 2000
- 2420
- 2820
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 10
- 15
- 18
- 20
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
