MANW 1100 Series

10" – 50" tall - Wet listed

The MANW 1100 Series delivers robust architectural performance with a steel housing and UV‑stabilized, high‑impact DR acrylic lensing. Designed for versatility, the fixture includes left and right keyhole slots for simplified installation and features top and bottom white acrylic lenses as standard. Optional features include photocell control, battery backup, and an NCL lens cover that eliminates up/down light for specialized applications. Available in five heights ranging from 10.5" to 50", the MANW 1100 Series supports a wide range of lumen outputs, color temperatures, and cage styles. With CRI > 90, universal 120/277V operation, and UL/CUL Wet Location listing, the MANW 1100 Series is engineered for long‑term reliability in demanding environments. Proudly made in America, with BABA‑compliant options always available.
Specification Sheet

Resources

  • Steel housing and chassis
  • UV‑stabilized, high‑impact resistant DR acrylic diffuser
  • Keyhole slots left and right for simplified installation
  • Top and bottom white acrylic lens (standard)
  • Optional NCL lens cover eliminates up/down light
  • Optional battery backup
  • Available heights: 10.5", 18", 26", 38", 50"
    • Width: 11.25"
    • Depth: 6"
    • Mount‑center options: 5.25", 9", 13", 19", 25"

  • LED light source
  • Dimming to 10% included (0–10V)
  • Optional line‑voltage TRIAC/ELV dimming (DIMLD)
  • CRI > 90
  • Replaceable LED module
  • Universal 120/277V standard
  • Optional photocell (21) — specify voltage (01 = 120V, 02 = 277V)
  • Optional battery backup (BB10)
  • UL and CUL Wet Location listed
  • 5‑year warranty on LED components

Features & Benefits
  • Wet Location rated for indoor or outdoor use
  • Wide range of lumen packages from 1600 lm to 9680 lm
  • Optional NCL lens cover eliminates up/down light for controlled illumination
  • Multiple cage styles (A, B, C, D, E, F, X) for architectural flexibility
  • Optional photocell for dusk‑to‑dawn operation
  • Optional battery backup for emergency egress illumination
  • Proudly made in America
  • BABA‑compliant options always available

Ideally Suited For
  • Multi‑family corridors
  • Hospitality environments
  • Commercial building interiors and exteriors
  • Educational facilities
  • Healthcare buildings
  • Government and public facilities
  • Any application requiring Wet Location durability and architectural styling

Ratings & Compliance

  • ARRA
  • Build America Buy America (BABA)
  • Buy America
  • Buy American Act (BAA)
  • JA8
  • Made in America
  • RoHS
  • Title 24
  • Wet

Lumens

  • 1600
  • 2420
  • 3235
  • 3412
  • 3630
  • 4840
  • 7260
  • 9680

Emergency Options

  • Integral EM Battery

Dimming Protocol

  • 0-10 V
  • ELV (Trailing Edge)
  • Phase Dimming
  • Triac (Leading Edge)

CRI

  • 91

Shape

  • Spherical

Lamp Source

  • LED
  • Screw-In LED

Listings

  • UL
  • cUL

Materials

  • Acrylic
  • Aluminum
  • Steel

Watts

  • 12
  • 18
  • 27
  • 29
  • 30
  • 36
  • 54
  • 72

Warranty

  • 5 yr
  • 10 yr

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K

Static LED Color

  • White

Voltage

  • 110 V
  • 110-120 V
  • 110-277 V
  • 120 V
  • 120-277 V
  • 347 V
  • Dual Volt
  • MVOLT
  • Multi Volt
  • Multi-Volt
  • UNV

Color / Finish

  • Anodized Silver
  • Brass Powder
  • Brushed Aluminum
  • Brushed Nickel
  • Butterscotch
  • Cornflower Blue
  • Custom
  • Deep Red
  • Gloss White
  • Medium Grey
  • Parkers Blue
  • Pearl Beige
  • Pewter
  • Sage
  • Sand Fossil
  • Satin Black
  • Satin Bronze
  • Shimmer Gray
  • Silver Gray
  • Textured Black
  • Textured Bronze
  • Textured Silver
  • Textured White
  • Tuscan Sun
  • Yolk White

Controls Options

  • Occupancy Sensor
  • Photocell
