MEDW SeriesMEDW Series
12" – 50" Tall - Wet listed Wall Mount
The MEDW-600-LED is a distinctive outdoor LED wall sconce engineered as a true downlight: a solid front shield prevents all forward light projection, directing illumination exclusively downward and earning compliance with Dark Sky requirements. The 6½" wide body is built on a steel housing and chassis, with ⅜" square extruded aluminum accent bars and rings available in multiple cage letter styles (A through K and custom X) and four accent materials — filigree, perforated screen, wire mesh, and waffle pattern — organized by four placement styles.
The fixture mounts via keyhole slots on the top and bottom, with six height options spanning 12" through 50". An optional photocell (adds 1½" depth) enables automated control, and battery backup and an optional concealed occupancy sensor (OCCHFB) are available. Optional 347V input accommodates Canadian projects. A field-replaceable LED module supports long-term maintenance efficiency.
The MEDW-600-LED is ADA compliant, UL and CUL WET location listed, and Build America Buy America Act compliant. A 5-year warranty applies to all LED components.
Resources
Material: Steel housing and chassis; ⅜" sq. extruded aluminum accent bars and rings
Lens Material: UV-stabilized, high impact resistant DR acrylic; optional cage accents (filigree, perforated, mesh, waffle)
Mounting: Keyhole slots top and bottom
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: H: 12" / 16" / 18" / 26" / 38" / 50"
W: 6½" D: 4" (standard) / 4⅜" (D1 cage styles)
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0-10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available.
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0-10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available.
The MEDW-600-LED is the ideal solution for projects that demand Dark Sky compliance and decorative cage customization in a single ADA-compliant downlight wall fixture.
Ideally Suited For:
• Dark Sky ordinance-sensitive communities
• Pedestrian pathways and plazas
• ADA-compliant building entries
• Parks, civic facilities, and institutional campuses
• Hospitality and resort exterior lighting
Key Features & Options:
• Solid front shield — downlight only, Dark Sky compliant
• Extensive cage options: 11 styles, 4 accent materials, 4 placement patterns
• ADA compliant at 4" depth
• Six heights: 12" through 50"
• Optional concealed occupancy sensor (OCCHFB)
• 0–10V dimming standard (to 10%)
• Optional battery backup — 90 min. emergency runtime
• Optional photocell (120V or 277V)
• Optional 347V input voltage
• Field-replaceable LED module
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ideally Suited For:
• Dark Sky ordinance-sensitive communities
• Pedestrian pathways and plazas
• ADA-compliant building entries
• Parks, civic facilities, and institutional campuses
• Hospitality and resort exterior lighting
Key Features & Options:
• Solid front shield — downlight only, Dark Sky compliant
• Extensive cage options: 11 styles, 4 accent materials, 4 placement patterns
• ADA compliant at 4" depth
• Six heights: 12" through 50"
• Optional concealed occupancy sensor (OCCHFB)
• 0–10V dimming standard (to 10%)
• Optional battery backup — 90 min. emergency runtime
• Optional photocell (120V or 277V)
• Optional 347V input voltage
• Field-replaceable LED module
• UL/CUL WET location listed
• BABA compliant — made in America
• 5-year LED component warranty
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- DarkSky Approved
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 1180
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 12
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
- Photocell
