LXTWLXTW
11" 16" Tall Damp lIsted Wall Lighting
The LXTW-LED is a sleek, ADA-compliant wall sconce featuring a 0.060" thick white textured polycarbonate diffuser mounted on a steel housing and chassis. Its open top-and-bottom design delivers both upward and downward ambient illumination for effective corridor and wall-washing light distribution. Optional alabaster lens materials — Amber Honey, Beige, and Opal — are available to tailor the light quality and aesthetic character to more premium design contexts. Custom cage styles are available from the factory.
Two sizes are offered — LXTW-11 (11" H × 10" W × 4" D) and LXTW-16 (15.5" H × 13.875" W × 4" D) — both compatible with a broad range of LED configurations and dimming options including 0–10V and TRIAC/ELV. Optional features include integral battery backup (0–10V only), a concealed occupancy sensor (O2A configuration only), and 347V input voltage for Canadian applications.
The LXTW-LED is ADA compliant, UL and CUL Listed for damp locations, Energy Star listed on select configurations, and proudly made in America. A 5-year LED component warranty is standard.
Resources
Material: Steel housing and chassis
Lens Material: 0.060" thick white textured polycarbonate (WTP); optional alabaster lens materials: Amber Honey (AHA), Beige Alabaster (BAA), Opal Alabaster (OAA)
Mounting: Wall mount — keyhole slots for standard J-box; custom cage styles available
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: LXTW-11: 11" H × 10" W × 4" D
Dimensions: LXTW-16: 15.5" H × 13.875" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The LXTW-LED is a practical, ADA-compliant wall sconce engineered for high-traffic commercial applications where reliable LED performance, code compliance, and design versatility all matter. Optional alabaster diffusers and occupancy sensor compatibility make it equally suited to premium hospitality and institutional settings.
Ideally Suited For:
• Healthcare facility corridors, patient wings, and accessible restrooms
• Hotel guestroom corridors and ADA-accessible public areas
• Educational institution hallways and common spaces
• Office building corridors, lobbies, and stairwells
• Government and civic buildings requiring ADA and energy code compliance
Key Features & Options:
• ADA compliant — 4" projection from wall
• Two sizes: LXTW-11 and LXTW-16
• White textured polycarbonate diffuser standard
• Optional alabaster lens materials: Amber Honey (AHA), Beige Alabaster (BAA), Opal Alabaster (OAA)
• Open top and bottom for up/down illumination
• Custom cage styles available — consult factory
• 0–10V dimming; TRIAC/ELV on qualifying configurations
• Optional integral battery backup (BB10 — 10 W, 90 minutes; 0–10V only)
• Optional concealed occupancy sensor (OCCHFB — O2A configuration only)
• Optional 347V input voltage
• Energy Star listed — select configurations
• Made in America
• 5-year LED component warranty (optional 10-year available)
• UL and CUL Listed — DAMP location
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 1600
- 2420
- 2820
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 10
- 12
- 15
- 18
- 20
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
