LEVW-LINEN
LEVW-App.jpgLEVW-LINEN
9" Tall Damp listed, ADA complaint Wall Lighting
The LEVW-LINEN wall sconce marries refined elegance with everyday practicality, featuring a steel housing and chassis paired with a floating outer frame that creates a distinctive illusion of depth. The washable laminated linen diffuser is available in a broad palette of textures and tones — including Sable, Black, White, Chocolate Textured, and Rapid Textured — allowing designers to tailor the aesthetic to any interior.
Dimming is standard and included to 10%, with 0–10V configurations available as well as TRIAC/ELV line-voltage dimming on qualifying configurations. A single size is offered at 9" H × 12" W × 4" D, with optional integral battery backup (BB10, 10 W for 90 minutes) available on 0–10V drivers only. Custom printed lens styles are available for branded or themed environments.
The LEVW-LINEN is ADA compliant at 4" depth, UL and CUL Listed for damp locations, Energy Star listed on select configurations, and Title 24/JA8 compliant on F1O and F1P configurations. It is proudly handcrafted in the United States and meets BABA standards. A 5-year LED component warranty is standard.
The LEVW-LINEN wall sconce marries refined elegance with everyday practicality, featuring a steel housing and chassis paired with a floating outer frame that creates a distinctive illusion of depth. The washable laminated linen diffuser is available in a broad palette of textures and tones — including Sable, Black, White, Chocolate Textured, and Rapid Textured — allowing designers to tailor the aesthetic to any interior.
Dimming is standard and included to 10%, with 0–10V configurations available as well as TRIAC/ELV line-voltage dimming on qualifying configurations. A single size is offered at 9" H × 12" W × 4" D, with optional integral battery backup (BB10, 10 W for 90 minutes) available on 0–10V drivers only. Custom printed lens styles are available for branded or themed environments.
The LEVW-LINEN is ADA compliant at 4" depth, UL and CUL Listed for damp locations, Energy Star listed on select configurations, and Title 24/JA8 compliant on F1O and F1P configurations. It is proudly handcrafted in the United States and meets BABA standards. A 5-year LED component warranty is standard.
Material: Steel housing and chassis
Lens Material: Washable laminated linen diffuser (opaque or textured; multiple color options)
Mounting: Wall mount — center lockup with hardware included; outer frame floats ¾" from wall
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: LEVW-9-LED: 9" H × 12" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
Title 24 / JA8: Yes — F1O & F1P configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and chassis
Lens Material: Washable laminated linen diffuser (opaque or textured; multiple color options)
Mounting: Wall mount — center lockup with hardware included; outer frame floats ¾" from wall
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: LEVW-9-LED: 9" H × 12" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Yes — on select configurations
Title 24 / JA8: Yes — F1O & F1P configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The LEVW-LINEN is a versatile, design-forward wall sconce purpose-built for spaces that demand both aesthetic impact and reliable performance. Its washable linen diffuser, floating frame detail, and ADA compliance make it a go-to solution across a wide spectrum of commercial and institutional environments.
Ideally Suited For:
• Fine dining restaurants and hospitality corridors
• Hotel guestrooms and public hallways
• Healthcare facilities and assisted living communities
• Educational institutions and campus buildings
• Multifamily residential common areas and lobbies
Key Features & Options:
• ADA compliant — 4" projection from wall
• Washable laminated linen diffuser in multiple color options (Sable, Black, White, Chocolate Textured, Rapid Textured)
• Outer frame extends ¾" to create floating illusion
• 0–10V dimming standard; TRIAC/ELV on qualifying configurations
• Optional integral battery backup (BB10 — 10 W, 90 minutes; 0–10V only)
• Energy Star listed — select configurations
• Title 24 / JA8 compliant — F1O & F1P configurations
• Custom printed lens styles available
• BABA compliant — proudly handcrafted in the USA
• 5-year LED component warranty (optional 10-year available)
• UL and CUL Listed — DAMP location
Ratings & Compliance
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Energy Star
- Interior
- JA8
- Made in America
- Title 24
Lumens
- 863
- 1361
- 1400
- 2420
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
CRI
- 90
Shape
- Square
Lamp Source
- Integrated LED
- LED
Listings
- UL
Materials
- Acrylic
- Linen
- Metal
- Steel
Watts
- 9
- 10
- 15
- 18
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Dimming Range
- 1%
- 10%
Distribution
- Wall Wash
- Wide
Static LED Color
- White
Voltage
- 120-277 V
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Brass Powder
- Butterscotch
- Cornflower Blue
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Peral Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Text Black
- Text Bronze
- Text White
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Infrared Sensor
- Occupancy Sensor
Dimensions
- L: 4 In. W: 12 In. H: 9 In.
Lamp Base
- Integrated
