PVFWPVFW
8" Tall Damp Listed Wall Sconce
The PVFW-LED is a clean, half-moon LED wall sconce featuring a steel housing and chassis with a white smooth acrylic diffuser as standard, and an optional white frosted glass diffuser for a more refined, luminous aesthetic. The fixture delivers an attractive upward wash of light ideal for corridor, lobby, and accent lighting applications. Center lockup mounting with hardware included simplifies installation to a standard junction box.
Dimming to 10% is standard via 0–10V. The PVFW-LED is ADA compliant at a 4" depth, making it suitable for corridor and accessible-space applications.
The PVFW-LED is UL and CUL Listed for DAMP locations and carries a 5-year warranty on LED components, with a 10-year option available. Proudly made in America.
Resources
Material: Steel housing and chassis
Lens Material: White smooth acrylic; optional white frosted glass (WFG)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
PVFW-8: H 8 1/4" × W 16 1/2" × D 4"
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The PVFW-LED from Lightway is a versatile half-moon LED wall sconce that delivers a warm upward wash of light in an ADA-compliant profile. With smooth acrylic or optional frosted glass diffuser options, it is an ideal choice for corridors, lobbies, and accent applications in commercial, healthcare, and multi-family environments.
Ideally Suited For:
• Commercial and institutional corridors
• Hotel lobbies and hospitality common areas
• Healthcare and assisted living corridors
• Multi-family residential hallways
• Retail and restaurant accent lighting
Key Features & Options:
• ADA compliant — 4" depth
• Half-moon form — upward wash light distribution
• White smooth acrylic or optional white frosted glass diffuser
• 0–10V dimming standard
• Center lockup — hardware included
• Field replaceable LED module
• 5-year LED warranty; 10-year option available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
- RoHS
- Title 24
Lumens
- 1210
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 9
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
