TBLW
13" Tall Wet Listed Wall Lighting
The TBLW‑LED Series is a Dark Sky compliant, ADA‑compliant architectural styling with rugged construction to create a versatile wall‑mounted LED solution for building exteriors, walkways, entries, and perimeter lighting. Built with a steel housing and chassis and paired with a clear smooth or white frosted acrylic diffuser, the TBLW‑LED provides clean, uniform illumination while maintaining a substantial yet ADA‑compliant profile.
Engineered for long‑term performance, the fixture includes a replaceable LED module, universal 120/277V operation, and dimming to 10%. It is UL and CUL listed for wet locations, ensuring reliable operation in exposed outdoor environments. Optional features include a photocell, all‑aluminum construction, and knockouts on all four sides for surface conduit applications. With multiple finishes, lumen packages, and color temperatures, the TBLW‑LED adapts easily to demanding architectural requirements. Proudly made in America, the series also offers Build America, Buy America Act (BABA) compliant configurations for federally funded projects.
Resources
- Steel housing and chassis
- Bottom lens options:
- CSA: Clear smooth acrylic
- WFA: White frosted acrylic
- Integral mounting plate
- Optional all‑aluminum construction
- Optional photocell — specify 120V or 277V
- Optional knockouts on all four sides (increases depth by 1/2")
- ADA compliant
- UL and CUL listed for wet locations
- Dimensions (TBLW‑13‑LED):
- Height: 13 3/4"
- Width: 7 3/4"
- Depth: 7 1/4"
- LED light source
- Dimming
- Replaceable LED module
- CRI > 90
- Universal 120/277V input
- UL and CUL listed for wet locations
- Color temperatures: 3000K, 3500K, 4000K
- Photocell available
- Optional battery backup
- 5‑year warranty on LED components
- Proudly made in America
- BABA‑compliant options always available
- Dark Sky compliant for reduced uplight and improved night‑sky protection
- ADA‑compliant design suitable for corridors and walkways
- Clear or frosted acrylic lens options to match architectural needs
- Optional photocell for dusk‑to‑dawn operation
- Optional knockouts for surface conduit installations
- Optional all‑aluminum construction for corrosion‑resistant environments
- Multiple finish options.
- High‑efficiency LED system reduces maintenance and energy costs
- Ideal for multi‑family housing, commercial buildings, entries, and perimeter lighting
- Durable construction suitable for harsh outdoor environments
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 2460
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV (Trailing Edge)
- Phase Dimming
- Triac (Leading Edge)
CRI
- 91
Shape
- Rectangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 24
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
