SUTCSUTC
16" Dia. Damp Listed Ceiling Mount
The SUTC‑LED Series combines classic styling with modern LED performance to create a versatile lighting solution for hallways, bedrooms, common areas, and multi‑family environments. Its steel pan construction ensures long‑term durability, while the frosted marbleized glass diffuser provides soft, even illumination. Available in a wide range of finishes and lumen packages, the SUTC‑LED supports both 0–10V and TRIAC/ELV dimming, making it adaptable to new construction or retrofit applications.
With universal 120/277V operation, high‑CRI LED modules, and optional battery backup, the SUTC‑LED delivers reliable, energy‑efficient performance. Select configurations meet Energy Star and Title 24/JA8 requirements, offering compliance for energy‑focused projects. A replaceable LED module and a 5‑year warranty on LED components ensure serviceability and peace of mind.
Proudly made in America.
The SUTC‑LED Series combines classic styling with modern LED performance to create a versatile lighting solution for hallways, bedrooms, common areas, and multi‑family environments. Its steel pan construction ensures long‑term durability, while the frosted marbleized glass diffuser provides soft, even illumination. Available in a wide range of finishes and lumen packages, the SUTC‑LED supports both 0–10V and TRIAC/ELV dimming, making it adaptable to new construction or retrofit applications.
With universal 120/277V operation, high‑CRI LED modules, and optional battery backup, the SUTC‑LED delivers reliable, energy‑efficient performance. Select configurations meet Energy Star and Title 24/JA8 requirements, offering compliance for energy‑focused projects. A replaceable LED module and a 5‑year warranty on LED components ensure serviceability and peace of mind.
Proudly made in America.
Material: Steel pan
Lens Material: Frosted marbleized glass
Mounting: Keyhole slots for standard J-Box — hardware included
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: SUTC-16: H 7¼" × W 15½" dia × D N/A
Lens Material: Frosted marbleized glass
Mounting: Keyhole slots for standard J-Box — hardware included
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: SUTC-16: H 7¼" × W 15½" dia × D N/A
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed — qualifying configurations
Title 24 / JA8: Compliant — F1P and F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed — qualifying configurations
Title 24 / JA8: Compliant — F1P and F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel pan
Lens Material: Frosted marbleized glass
Mounting: Keyhole slots for standard J-Box — hardware included
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: SUTC-16: H 7¼" × W 15½" dia × D N/A
Lens Material: Frosted marbleized glass
Mounting: Keyhole slots for standard J-Box — hardware included
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: SUTC-16: H 7¼" × W 15½" dia × D N/A
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed — qualifying configurations
Title 24 / JA8: Compliant — F1P and F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed — qualifying configurations
Title 24 / JA8: Compliant — F1P and F1Q configurations only
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The SUTC-LED from Lightway brings American craftsmanship and engineering excellence to exterior and architectural lighting. Combining enduring design with state-of-the-art LED technology, it is an ideal choice for projects requiring long-term performance, design versatility, and compliance confidence. Field-replaceable LED modules ensure easy maintenance, and a comprehensive range of finishes and lens options make specification straightforward for any project.
Ideally Suited For:
• California Title 24-compliant residential and commercial ceilings
• Hallways and stairwells with occupancy sensing
• Multi-family residential common areas
• Hospitality guest corridors
• Commercial office ceilings
Key Features & Options:
• Classic frosted marbleized glass diffuser
• Title 24/JA8 compliant (F1P & F1Q)
• Optional concealed occupancy sensor
• Optional battery backup
• Energy Star listed
• Keyhole slot installation for standard J-Box
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 2057
- 2115
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 92
Shape
- Dome
- Round
Lamp Source
- Integrated LED
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Aluminum
- Glass
- Steel
Watts
- 9
- 10
- 13
- 15
- 23
Warranty
- 5 yr
- 10 yr
CCT
- 2000K
- 3000K
- 3500K
- 4000K
- 5000K
Diameter
- 16
Diffuser
- Opal Alabaster
Dimming Range
- 1%
- 10%
Distribution
- Wide
Mounting
- Ceiling
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
Lamp Base
- E26
- Integrated
- Medium Base
