CYVWCYVW
24" Tall Damp Listed Wall Sconce
The CYVW-LED is a refined cylindrical wall fixture built on a steel housing and chassis with distinctive metal spun end caps and a seamless extruded frosted acrylic tube lens for a premium, architectural appearance. Available in a 24" length, the CYVW-LED mounts to a standard 2×4 box or opening oriented to match the fixture's linear dimension, with horizontal or vertical mounting options.
CRI >90 standard with both 0–10V and TRIAC/ELV line-voltage dimming options available. Optional 347V input voltage supports a wide range of electrical system requirements.
BABA compliant, UL and CUL listed for DAMP locations, and backed by a 5-year LED component warranty.
The CYVW-LED is a refined cylindrical wall fixture built on a steel housing and chassis with distinctive metal spun end caps and a seamless extruded frosted acrylic tube lens for a premium, architectural appearance. Available in a 24" length, the CYVW-LED mounts to a standard 2×4 box or opening oriented to match the fixture's linear dimension, with horizontal or vertical mounting options.
CRI >90 standard with both 0–10V and TRIAC/ELV line-voltage dimming options available. Optional 347V input voltage supports a wide range of electrical system requirements.
BABA compliant, UL and CUL listed for DAMP locations, and backed by a 5-year LED component warranty.
Material: Steel housing and chassis with metal spun end caps
Lens Material: Seamless extruded white frosted acrylic tube lens
Mounting: Mounts to 2×4 box/opening oriented to match fixture's linear dimension; horizontal or vertical mounting
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
CYVW-24: 24" L × 5" W × 3" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and chassis with metal spun end caps
Lens Material: Seamless extruded white frosted acrylic tube lens
Mounting: Mounts to 2×4 box/opening oriented to match fixture's linear dimension; horizontal or vertical mounting
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
CYVW-24: 24" L × 5" W × 3" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The CYVW-LED cylindrical wall fixture elevates the standard tube sconce with metal spun end caps and a seamless frosted acrylic lens, delivering CRI >90 LED performance in a refined, architectural profile suited to upscale commercial and hospitality interiors. BABA compliant and made in America.
Ideally Suited For
• Upscale hotel corridor and guestroom entry wall lighting
• Restaurant and fine dining ambient wall illumination
• Commercial office building lobby and boardroom wall lighting
• Healthcare facility executive suite and reception lighting
• Senior living community dining and social space wall lighting
Key Features & Options
• CRI >90 standard — premium color rendering
• Metal spun end caps — distinctive architectural detailing
• Seamless extruded frosted acrylic tube lens
• Horizontal or vertical mounting flexibility
• Mounts to standard 2×4 box — no special hardware required
• Optional 347V input voltage
• 0–10V and TRIAC/ELV line-voltage dimming
• Proudly made in America — BABA compliant
• 5-year LED warranty; optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
- RoHS
- Title 24
Lumens
- 2350
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Tubular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 15
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
