10" to 26" Tall Wet Listed Wall Lighting
The DKAW-LED is a bold cylindrical outdoor wall sconce constructed from a steel housing, chassis, and cage with a distinctive shield design offset from the .10" thick extruded white acrylic lens. Top and bottom acrylic lenses are standard, delivering a refined up/down lighting effect. Available in four heights — 10", 16", 22¼", and 26½" — the DKAW-LED is designed for a wide range of exterior architectural applications.
CRI >90 standard with 0–10V dimming included. Optional features include a photocell (120V or 277V, increases fixture depth 1½"), all-aluminum construction, a J-Box with knockouts on all sides, and battery backup (0–10V only, excluding the DKAW-10).
UL and CUL listed for WET locations and backed by a 5-year LED component warranty — see the configuration table for full details.
Resources
Material: Steel housing, chassis, and cage
Lens Material: 0.10" thick extruded white acrylic diffuser (WSA); shield design offset from lens
Mounting: Integral mounting plate; keyhole slots left and right
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Proudly made in America — BABA compliant options always available.
Dimensions: DKAW-10: 10" H × 9" W × 6" D
DKAW-16: 16" H × 9" W × 6" D
DKAW-22: 22¼" H × 9" W × 6" D
DKAW-26: 26½" H × 9" W × 6" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — WET location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The DKAW-LED is a versatile multi-size outdoor shield-design sconce delivering CRI > 90 performance across a wide wattage range, backed by Lightway's American manufacturing and comprehensive warranty.
Ideally Suited For:
• Residential building entries
• Hospitality property exteriors
• Commercial facade lighting
• Outdoor corridor and pathway walls
• Mixed-use development exteriors
Key Features & Options:
• Four heights: 10", 16", 22", 26"
• CRI > 90 for premium color rendering
• Up/down light distribution through shield design
• Optional photocell (21): 120V or 277V — adds 1½" depth
• Optional battery backup BB10 (excludes DKAW-10)
• Optional J-Box with knockouts all sides (option 39)
• Optional all-aluminum construction (option 42)
• Optional Brushed Nickel and Brass Powder finishes
• Integral power supply with replaceable LED modules
• 5-year LED component warranty
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Made in America
- RoHS
- Title 24
- Wet
Lumens
- 1600
- 2000
- 2420
- 3630
- 4000
- 4840
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Spherical
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 12
- 15
- 18
- 27
- 29
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Photocell
