AVAWAVAW
10" Tall Damp Listed Wall Sconce
The AVAW-LED is a distinctive wedge-profile wall sconce with steel housing and chassis and a .080" thick white smooth or textured polycarbonate diffuser. Optional alabaster lenses (amber honey, beige, opal) are available for decorative applications. Custom cage styles can be configured. Center lockup hardware is included. The 4" depth provides ADA compliance.
LED performance delivers CRI greater than 90, 3-step MacAdam binning, and lumen maintenance exceeding 60,000 hours. The replaceable LED module is standard. Dimming is available to 10% or 1% via 0–10V. The standard configuration is 6W/800 lumens. Operates on universal 120–277V; optional 347V available.
The AVAW-LED is ADA compliant (4" depth) and UL and CUL listed for DAMP locations. Backed by a 5-year warranty on LED components with an optional 10-year warranty.
LED performance delivers CRI greater than 90, 3-step MacAdam binning, and lumen maintenance exceeding 60,000 hours. The replaceable LED module is standard. Dimming is available to 10% or 1% via 0–10V. The standard configuration is 6W/800 lumens. Operates on universal 120–277V; optional 347V available.
The AVAW-LED is ADA compliant (4" depth) and UL and CUL listed for DAMP locations. Backed by a 5-year warranty on LED components with an optional 10-year warranty.
The AVAW-LED is a distinctive wedge-profile wall sconce with steel housing and chassis and a .080" thick white smooth or textured polycarbonate diffuser. Optional alabaster lenses (amber honey, beige, opal) are available for decorative applications. Custom cage styles can be configured. Center lockup hardware is included. The 4" depth provides ADA compliance.
LED performance delivers CRI greater than 90, 3-step MacAdam binning, and lumen maintenance exceeding 60,000 hours. The replaceable LED module is standard. Dimming is available to 10% or 1% via 0–10V. The standard configuration is 6W/800 lumens. Operates on universal 120–277V; optional 347V available.
The AVAW-LED is ADA compliant (4" depth) and UL and CUL listed for DAMP locations. Backed by a 5-year warranty on LED components with an optional 10-year warranty.
LED performance delivers CRI greater than 90, 3-step MacAdam binning, and lumen maintenance exceeding 60,000 hours. The replaceable LED module is standard. Dimming is available to 10% or 1% via 0–10V. The standard configuration is 6W/800 lumens. Operates on universal 120–277V; optional 347V available.
The AVAW-LED is ADA compliant (4" depth) and UL and CUL listed for DAMP locations. Backed by a 5-year warranty on LED components with an optional 10-year warranty.
Material: Steel housing and chassis
Lens Material: 0.080" thick white smooth or textured polycarbonate (WTP / WSP); optional alabaster lenses (AHA, BAA, OAA)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Proudly made in America — BABA compliant options always available.
Dimensions: AVAW-10: 10" H × 14" W × 4" D
Lens Material: 0.080" thick white smooth or textured polycarbonate (WTP / WSP); optional alabaster lenses (AHA, BAA, OAA)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Proudly made in America — BABA compliant options always available.
Dimensions: AVAW-10: 10" H × 14" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and chassis
Lens Material: 0.080" thick white smooth or textured polycarbonate (WTP / WSP); optional alabaster lenses (AHA, BAA, OAA)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Proudly made in America — BABA compliant options always available.
Dimensions: AVAW-10: 10" H × 14" W × 4" D
Lens Material: 0.080" thick white smooth or textured polycarbonate (WTP / WSP); optional alabaster lenses (AHA, BAA, OAA)
Mounting: Center lockup — hardware included
ADA Compliant: Yes — 4" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
Proudly made in America — BABA compliant options always available.
Dimensions: AVAW-10: 10" H × 14" W × 4" D
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The AVAW-LED is a unique wedge-profile ADA-compliant wall sconce that delivers soft ambient illumination with an architectural edge. Its customizable cage and optional alabaster lenses suit both modern and transitional interior environments.
Ideally Suited For:
• Hotel and hospitality interiors
• Residential and multifamily corridors
• Retail accent lighting
• Commercial lobby and lounge areas
• Institutional interior spaces
Key Features & Options:
• ADA compliant — 4" depth
• Distinctive wedge profile for architectural interest
• Optional alabaster lenses — amber honey, beige, opal
• Custom cage styles available
• Dimming to 10% or 1%
• Optional 347V input voltage
• Proudly made in America — BABA compliant options always available.
• 5-year warranty with optional 10-year upgrade
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
- RoHS
- Title 24
Lumens
- 800
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 91
Shape
- Triangular
Lamp Source
- LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 6
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
