ETOCETOC
12" or 14" Damp Listed Ceiling Mount
The ETOC-LED is a versatile flush-mount ceiling fixture with a steel housing and chassis built for lasting durability. The standard diffuser is .080" thick white textured polycarbonate, and optional .080" thick acrylic alabaster lenses — in amber honey, beige, and opal — provide elegant design flexibility. Available in 12" and 14" widths, the ETOC-LED adapts seamlessly to corridors, restrooms, and common areas where reliable overhead illumination is required.
With CRI >90 standard and 0–10V dimming across most configurations, the ETOC-LED also supports TRIAC/ELV line-voltage dimming on select options. An integrated concealed occupancy sensor (OCCHFA) is available for energy-saving automatic control. Optional battery backup and 347V voltage expand its specification range. White smooth polycarbonate (WSP) is an additional diffuser choice.
Energy Star listed on qualifying configurations, UL and CUL listed for DAMP locations, and covered by a 5-year LED component warranty. Consult the configuration table for full compliance and configuration details.
The ETOC-LED is a versatile flush-mount ceiling fixture with a steel housing and chassis built for lasting durability. The standard diffuser is .080" thick white textured polycarbonate, and optional .080" thick acrylic alabaster lenses — in amber honey, beige, and opal — provide elegant design flexibility. Available in 12" and 14" widths, the ETOC-LED adapts seamlessly to corridors, restrooms, and common areas where reliable overhead illumination is required.
With CRI >90 standard and 0–10V dimming across most configurations, the ETOC-LED also supports TRIAC/ELV line-voltage dimming on select options. An integrated concealed occupancy sensor (OCCHFA) is available for energy-saving automatic control. Optional battery backup and 347V voltage expand its specification range. White smooth polycarbonate (WSP) is an additional diffuser choice.
Energy Star listed on qualifying configurations, UL and CUL listed for DAMP locations, and covered by a 5-year LED component warranty. Consult the configuration table for full compliance and configuration details.
Material: Steel housing and chassis
Lens Material: .080" thick white textured polycarbonate standard; white smooth polycarbonate optional; optional .080" thick acrylic alabaster lenses (Amber Honey, Beige, Opal)
Mounting: Center lockup — hardware included; flush ceiling mount
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
ETOC-12: 5 3/8" H × 12" W
ETOC-14: 5 3/8" H × 14" W
Lens Material: .080" thick white textured polycarbonate standard; white smooth polycarbonate optional; optional .080" thick acrylic alabaster lenses (Amber Honey, Beige, Opal)
Mounting: Center lockup — hardware included; flush ceiling mount
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
ETOC-12: 5 3/8" H × 12" W
ETOC-14: 5 3/8" H × 14" W
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Steel housing and chassis
Lens Material: .080" thick white textured polycarbonate standard; white smooth polycarbonate optional; optional .080" thick acrylic alabaster lenses (Amber Honey, Beige, Opal)
Mounting: Center lockup — hardware included; flush ceiling mount
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
ETOC-12: 5 3/8" H × 12" W
ETOC-14: 5 3/8" H × 14" W
Lens Material: .080" thick white textured polycarbonate standard; white smooth polycarbonate optional; optional .080" thick acrylic alabaster lenses (Amber Honey, Beige, Opal)
Mounting: Center lockup — hardware included; flush ceiling mount
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
ETOC-12: 5 3/8" H × 12" W
ETOC-14: 5 3/8" H × 14" W
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The ETOC-LED flush-mount ceiling fixture brings Lightway's trusted quality to overhead lighting applications, with integrated sensor options and alabaster accent lenses that elevate everyday spaces. Its Energy Star listings, Made-in-America manufacturing, and wide configuration range make it an efficient and flexible specification.
Ideally Suited For
• Corridor and hallway lighting
• Restroom and utility room overhead lighting
• Healthcare facility patient room lighting
• Stairwell and exit pathway lighting
• Commercial common area and lobby ceiling lighting
Key Features & Options
• Energy Star listed on select configurations
• Optional concealed occupancy sensor (OCCHFA)
• Optional alabaster acrylic lenses (Amber Honey, Beige, Opal)
• White smooth polycarbonate (WSP) diffuser option
• Optional battery backup (0–10V only)
• Optional 347V input voltage
• 0–10V and TRIAC/ELV dimming
• 90 CRI option available — consult factory
• Custom cage styles available
• Proudly made in America — BABA compliant options available
• 5-year LED warranty; optional 10-year warranty available
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 2057
- 2115
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 81
- 91
Shape
- Rectangular
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 10
- 13
- 15
- 23
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
