LCACLCAC
19" or 24" Damp listed Ceiling
The LCAC-LED is a flush-mount cone luminaire featuring a steel housing with a powder-coated finish. The side diffuser is a translucent bonded linen material available in white linen, chocolate textured, rapid textured, and black textured acrylic. The standard bottom diffuser is white textured acrylic. Available in 19" and 24" diameters, the fixture's tapered cone profile creates a distinctive ceiling presence suited to hospitality, healthcare, and high-end commercial interiors. A typical lead time of six weeks applies; consult factory for minimum order quantities and setup fees.
Both 0–10V and TRIAC/ELV dimming configurations are supported. Energy Star listed options are available across all configurations. An optional concealed occupancy sensor (OCCHFA) enables demand-based control. Battery backup (BB10 — requires a 1¾" extension ring, 0–10V only) is available on the LCAC-24 only. Optional 90 CRI and an aluminum pan accessory (option 42) can also be specified. For a pendant-mounted version, see the LCAH.
The LCAC-LED is UL and CUL listed for DAMP locations and backed by a 5-year warranty on LED components with an optional 10-year term.
Resources
Material: Steel housing with powder-coated finish
Lens Material: Side: translucent bonded linen (WLA, CTA, RTA, BTA); bottom: white textured acrylic (WTA standard); optional trim — consult factory
Mounting: Mounting kit included for standard J-Box
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: 19" dia × 8" H (top), 12" dia (bottom) (LCAC-19)
Dimensions: 24" dia × 8" H (top), 16" dia (bottom) (LCAC-24)
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 80 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Available on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The LCAC-LED's tapered cone form and translucent linen diffuser create a striking ceiling element suited to hospitality and healthcare interiors, with Energy Star credentials, optional occupancy sensing, and battery backup for comprehensive specification compliance.
Ideally Suited For:
• Hotel and hospitality lobby and dining area ceiling lighting
• Healthcare facility waiting rooms and patient common areas
• Corporate office reception and common area lighting
• Multi-family residential lobby and amenity spaces
• Upscale retail and boutique interior environments
Key Features & Options:
• Energy Star listed on qualifying configurations
• Two sizes: 19" and 24" diameters
• Tapered cone flush-mount profile
• Translucent linen side diffuser in multiple color options
• Optional concealed occupancy sensor (OCCHFA)
• Optional battery backup (BB10 — 10W, 90-min runtime, LCAC-24 only)
• Optional aluminum pan (option 42)
• 0–10V and TRIAC/ELV dimming options
• Optional 90 CRI — consult factory
• Typical 6-week lead time — consult factory for minimums
• Field-replaceable LED module
• BABA compliant — proudly made in America
• 5-year warranty; optional 10-year term
Ratings & Compliance
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 1065
- 1400
- 1724
- 2115
- 2540
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 81
- 91
Shape
- Round
Lamp Source
- Integrated LED
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Steel
Watts
- 9
- 10
- 13
- 15
- 23
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Diameter
- 20
- 24
Diffuser
- Black Textured Acrylic
- Chocolate Textured Acrylic
- Rapid Textured Acrylic
- White Frosted Acrylic
- White Linen Acrylic
- White Smooth Acrylic
Dimming Range
- 1%
- 10%
Distribution
- Wide
Mounting
- Ceiling
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
Lamp Base
- E26
- Integrated
- Medium Base
Similar Products
Linen Fixture Series Collection
BABAA Fixtures Collection
LCFW-WOODS
