12" or 16" Damp Listed Ceiling Mount
The CALC-LED is a square flush-mount ceiling fixture featuring a steel housing and chassis with a standard .080" thick white textured polycarbonate diffuser and optional white smooth polycarbonate. Optional .080" thick acrylic alabaster lenses — in amber honey, beige, and opal — provide elegant decorative versatility. Custom cage styles are available. Available in 12" and 16" sizes with center lockup mounting hardware included.
CRI >80 standard with 0–10V and TRIAC/ELV dimming options. Optional features include Energy Star, concealed occupancy sensor (OCCHFA, 20W only), 90 CRI, optional 347V voltage, and battery backup (0–10V only).
Energy Star listed on qualifying configurations, UL and CUL listed for DAMP locations, and backed by a 5-year LED component warranty.
Resources
Material: Steel housing and steel chassis
Lens Material: .080" white textured polycarbonate standard; white smooth polycarbonate optional; optional .080" acrylic alabaster lenses (Amber Honey, Beige, Opal)
Mounting: Center lockup — hardware included
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions:
CALC-12: 4" H × 11½" W
CALC-16: 4" H × 15½" W
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; TRIAC/ELV on qualifying configurations. Consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
Energy Star: Listed on qualifying configurations
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The CALC-LED square ceiling fixture combines decorative cage styling with reliable LED performance, offering Energy Star listings, optional alabaster acrylic lenses, and occupancy sensor capabilities for versatile commercial and institutional ceiling applications. Made in America.
Ideally Suited For
• Commercial corridor and lobby ceiling lighting
• Healthcare facility patient and common area lighting
• Hotel and hospitality guestroom and corridor overhead lighting
• Educational institution hallway and classroom lighting
• Senior living community common area ceiling lighting
Key Features & Options
• Energy Star listed on qualifying configurations
• Optional alabaster acrylic lenses (Amber Honey, Beige, Opal)
• Optional white smooth polycarbonate diffuser
• Custom cage styles available
• Optional concealed occupancy sensor (OCCHFA — 20W configurations)
• Optional battery backup (0–10V only)
• Optional 347V input voltage
• 90 CRI option available — consult factory
• 0–10V and TRIAC/ELV dimming options
• Proudly made in America — BABA compliant options always available
• 5-year LED warranty; optional 10-year warranty available
Ratings & Compliance
- ADA
- ARRA
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- JA8
- Made in America
- RoHS
- Title 24
Lumens
- 863
- 1361
- 1400
- 2057
- 2115
- 2420
- 4000
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- ELV
- Phase Dimming
- Triac
CRI
- 81
- 91
Shape
- Square
Lamp Source
- LED
- Screw-In LED
Listings
- UL
- cUL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Watts
- 9
- 10
- 13
- 15
- 18
- 23
- 36
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Static LED Color
- White
Voltage
- 110 V
- 110-120 V
- 110-277 V
- 120 V
- 120-277 V
- 347 V
- Dual Volt
- MVOLT
- Multi Volt
- Multi-Volt
- UNV
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Custom
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Occupancy Sensor
