LBKW-WOODS
LBKW Appshot.jpgLBKW-WOODS
Your Choice of Multiple Faux Wood Wall Sconce 15” and 27”
The LBKW-WOODS is a handcrafted vertical wall sconce with a welded steel housing and chassis. The front diffuser is a faux wood grain lens available in four species — maple, bamboo, teak, and walnut — in either opaque or semi-translucent finish. The surface is easily cleaned with a damp cloth. A white acrylic side lens fully encases all four vertical sides, providing uniform ambient illumination and a soft perimeter glow alongside the wood-grain feature face. Nine design overlay patterns (A through I, plus custom X) give designers a wide creative range, and fully custom designs are available.
Available in 15" and 27" heights, the fixture mounts to a standard J-Box. Standard 0–10V dimming is included. An optional concealed occupancy sensor (OCCHFA) provides demand-based control, and battery backup (BB10 — 10W for 90 minutes, 0–10V only) enables emergency egress applications. CRI exceeds 90, and 24 metal frame finishes are
available.
The LBKW-WOODS is ADA compliant, Build America, Buy America Act compliant, UL and CUL listed for DAMP locations, and backed by a 5-year warranty on LED components.
The LBKW-WOODS is a handcrafted vertical wall sconce with a welded steel housing and chassis. The front diffuser is a faux wood grain lens available in four species — maple, bamboo, teak, and walnut — in either opaque or semi-translucent finish. The surface is easily cleaned with a damp cloth. A white acrylic side lens fully encases all four vertical sides, providing uniform ambient illumination and a soft perimeter glow alongside the wood-grain feature face. Nine design overlay patterns (A through I, plus custom X) give designers a wide creative range, and fully custom designs are available.
Available in 15" and 27" heights, the fixture mounts to a standard J-Box. Standard 0–10V dimming is included. An optional concealed occupancy sensor (OCCHFA) provides demand-based control, and battery backup (BB10 — 10W for 90 minutes, 0–10V only) enables emergency egress applications. CRI exceeds 90, and 24 metal frame finishes are
available.
The LBKW-WOODS is ADA compliant, Build America, Buy America Act compliant, UL and CUL listed for DAMP locations, and backed by a 5-year warranty on LED components.
Material: Welded steel housing and chassis
Lens Material: Front: faux wood grain lens — Maple (DV1/DT1), Bamboo (DV2/DT2), Teak (DV3/DT3), Walnut (DV4/DT4) in opaque or semi-translucent; side: white acrylic lens; 9 design overlays (A–I) plus custom (X)
Mounting: Mounts to standard J-Box; custom design styles available
ADA Compliant: Yes — 3.5" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: 15" H × 6.5" W × 3.5" D (LBKW-15)
Dimensions: 27" H × 6.5" W × 3.5" D (LBKW-27)
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
Resources
Material: Welded steel housing and chassis
Lens Material: Front: faux wood grain lens — Maple (DV1/DT1), Bamboo (DV2/DT2), Teak (DV3/DT3), Walnut (DV4/DT4) in opaque or semi-translucent; side: white acrylic lens; 9 design overlays (A–I) plus custom (X)
Mounting: Mounts to standard J-Box; custom design styles available
ADA Compliant: Yes — 3.5" depth
Finish: Non-VOC powder-coat and environmentally responsible low-VOC metal finishing options. Custom finishes — consult factory.
BABA: Proudly made in America — BABA compliant options always available.
Dimensions: 15" H × 6.5" W × 3.5" D (LBKW-15)
Dimensions: 27" H × 6.5" W × 3.5" D (LBKW-27)
Replaceable LED Module: Yes — field replaceable
3-Step MacAdam Binning: Standard
Lumens: Source lumens — see configuration table
Lumen Maintenance: > 60,000 hours
Integral Driver: Standard
Dimming: 0–10V; consult factory for other options.
Voltage: 120–277V universal standard
CRI: > 90 Standard
CCT Options: 2700K – 3000K – 3500K – 4000K – 5000K
UL / CUL Listing: UL and CUL Listed — DAMP location
Warranty: 5-year warranty on LED components with optional 10-year warranty available
The LBKW-WOODS brings natural biophilic warmth to interior wall lighting through four faux wood species, nine design overlay patterns, and white acrylic side glow — all in an ADA-compliant, BABA-certified, easily cleanable sconce with optional occupancy sensor and battery backup.
Ideally Suited For:
• Biophilic-design corporate offices and wellness centers
• Hotel and resort branded interior corridors
• Healthcare facility patient areas and waiting rooms
• Multi-family residential amenity and corridor spaces
• Educational campus interior hallways
Key Features & Options:
• ADA compliant — 3.5" depth
• Build America, Buy America Act compliant
• Four faux wood species: maple, bamboo, teak, walnut
• Opaque (DV) and semi-translucent (DT) wood diffuser options
• Nine standard design overlay patterns; custom designs available
• White acrylic side lens — ambient perimeter glow
• Two sizes: 15" and 27"
• 24 metal frame finish options
• Optional concealed occupancy sensor (OCCHFA)
• Optional battery backup (BB10 — 10W, 90-min runtime)
• CRI > 90 standard
• Surface cleanable with damp cloth
• Field-replaceable LED module
• BABA compliant — proudly made in America
• 5-year warranty; optional 10-year term
Ratings & Compliance
- Build America Buy America (BABA)
- Buy America
- Buy American Act (BAA)
- Damp
- Made in America
Lumens
- 1400
- 2420
- 3654
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
CRI
- 90
Shape
- Rectilinear
Lamp Source
- Integrated LED
- LED
Listings
- UL
Materials
- Acrylic
- Metal
- Plastic
- Steel
- Wood
Watts
- 9
- 18
- 32
Warranty
- 5 yr
- 10 yr
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Dimming Range
- 1%
- 10%
Distribution
- Wall Wash
Static LED Color
- White
Voltage
- Multi Volt
- Multi-Volt
- UNV
Circuit
- Single
Color / Finish
- Anodized Silver
- Brass Powder
- Brushed Aluminum
- Brushed Nickel
- Butterscotch
- Cornflower Blue
- Deep Red
- Gloss White
- Medium Grey
- Parkers Blue
- Pearl Beige
- Peral Beige
- Pewter
- Sage
- Sand Fossil
- Satin Black
- Satin Bronze
- Shimmer Gray
- Silver Gray
- Text Black
- Text Bronze
- Text White
- Textured Black
- Textured Bronze
- Textured Silver
- Textured White
- Tuscan Sun
- Yolk White
Controls Options
- Infrared Sensor
- Integral Sensor
- Occupancy Sensor
Dimensions
- L: 3.5 In. W: 6.5 In. H: 15 In.
- L: 3.5 In. W: 6.5 In. H: 27 In.
Lamp Base
- Integrated
